5.12 Typical Characteristics
Figure 5-4 Output High Drive Current
vs Temperature
| IN+ = High | IN- = Low |
Figure 5-8 IVCCQ Supply Current vs Input Frequency
| IN+ = Low | IN- = Low |
Figure 5-12 VCC
UVLO vs Temperature
| VCC = 3.3V | VDD=18V | CL = 100pF |
| RON = 0Ω | ROFF = 0Ω |
| VCC = 3.3V | VDD=18V | CL = 10nF |
| RON = 0Ω | ROFF = 0Ω |
Figure 5-18 VOUTPD Output Active Pulldown Voltage vs Temperature
Figure 5-5 Output Low Driver Current
vs Temperature
| IN+ = Low | IN- = Low |
| IN+ = High | IN- = Low |
Figure 5-13 VDD
UVLO vs Temperature
| VCC = 3.3V | VDD=18V | CL = 100pF |
| RON = 0Ω | ROFF = 0Ω |
| VCC = 3.3V | VDD=18V | CL = 10nF |
| RON = 0Ω | ROFF = 0Ω |
Figure 5-21 VCLMPTH Miller Clamp Threshold Voltage vs
Temperature
