8 EVM Assembly Drawing and PCB Layout
The following figures show the design of the TPS549A20EVM-737 printed circuit board (see Figure 8-1, Figure 8-2, Figure 8-3, Figure 8-4, Figure 8-5, Figure 8-6, Figure 8-7, and Figure 8-8). The EVM has been designed using a six-layer 2-oz copper-circuit board.
Figure 8-1 TPS549A20EVM-587 Top-Layer Assembly Drawing
Figure 8-2 TPS549A20EVM-587 Bottom-Layer Assembly Drawing
Figure 8-3 TPS549A20EVM-587 Top Layer, Copper
Figure 8-4 TPS549A20EVM-587 Layer Two, Copper
Figure 8-5 TPS549A20EVM-587 Layer Three, Copper
Figure 8-6 TPS549A20EVM-587 Layer Four, Copper
Figure 8-7 TPS549A20EVM-587 Layer Five, Copper
Figure 8-8 TPS549A20EVM-587 Bottom Layer, Copper
