6.7 Typical Characteristics
TA = 25°C, VIN = 12 V, fSW = 1 MHz, CBoost = 2 x 22 μF/35 V (unless otherwise noted)
| L = 4.7 μH |
| V(LNB) = 18.2 V |
Figure 6-5 Shutdown Current vs Junction Temperature
| V(LNB) = 13.4 V |
Figure 6-4 Input Supply Quiescent Current vs Junction Temperature
| ILOAD = 650 mA |
