7.9 Typical Characteristics
VIN = 12 V, fSW = 2.1 Mhz ,TA = 25°C, unless otherwise specified.
| fSW = 2.1 MHz | VOUT = 3.3 V |
| fSW = 2.1 MHz | VOUT = 3.3 V | PFM version |
| fSW = 2.1 MHz | VOUT = 5 V | PFM version |
Figure 7-9 Reference Voltage versus Temperature
| fSW = 2.1 MHz | VOUT = 5 V |
| fSW = 2.1 MHz | VOUT = 5 V | PFM version |
| fSW = 2.1 MHz | VOUT = 3.3 V | PFM version |
Figure 7-10 HS
and LS Current Limit versus Temperature
