1 特性
2 應用
- 多載波、多模式蜂窩基站
- 雷達和智能天線陣列
- 炮彈制導
- 電機控制反饋
- 網絡和矢量分析器
- 通信測試設備
- 無損檢測
- 微波接收器
- 軟件定義無線電 (SDR)
- 正交和分集無線電接收器
3 說明
ADC344x 器件屬于高線性度、超低功耗、四通道、14 位、25MSPS 至 125MSPS 模數轉換器 (ADC) 系列。此類器件專門設計用于支持具有寬動態范圍需求且要求苛刻的高輸入頻率信號。輸入時鐘分頻器可給予系統時鐘架構設計更高的靈活性，同時 SYSREF 輸入可實現整個系統同步。
ADC344x 系列支持串行低壓差分信令 (LVDS)，從而減少接口線路的數量，實現高系統集成密度。串行 LVDS 接口為雙線制，通過兩個 LVDS 對串行輸出每個 ADC 數據。此外，也可提供單線制串行 LVDS 接口。內部鎖相環 (PLL) 會將傳入的 ADC 采樣時鐘加倍，以獲得串行輸出各通道的 14 位輸出數據時所使用的位時鐘。除了串行數據流之外，數據幀和位時鐘也作為 LVDS 輸出進行傳送。
- 要了解所有可用封裝，請參閱數據表末尾的可訂購產品附錄。
